Electrical Specifications
Rated Capacity (0.5C, 25°C): 100Ah
Nominal Voltage: 12.8V
Energy: 1280Wh
Cycle Life (0.5C/1C, 25℃): 6000 Cycles (80% DOD, 80% EOL)
Temperature Parameters
Operation Temperature Range
Charge: 32°F to 131°F (0°C to 55°C)
Discharge: -4°F to 131°F (-20°C to 55°C)
Storage Temperature Range: 32°F to 113°F (0°C to 45°C)
Operation Relative Humidity: 5% to 95%
Charging Parameters
Voltage Range:10.8V to 14.8V
Maximum Continuous Charge Current: 100A
Discharging Parameters
Maximum Continuous Discharge Current: 150A
Peak Discharge Current: 300A@30s
Mechanical Specifications
Dimension (L x W x H): 10.24x6.61x8.23in/260x168×209 mm
Weight: 21.83 lbs / 9.9 kg
Terminal Bolt Size: M8 x 1.25 x 12 mm
Protection Rating: IP67
Certifications: RCM, MSDS, UN38.3, FCC, CE, PSE, IC, RoHS, and UKCA
Warranty: 5-year material warranty
